Mersen NHG2-100 Blade Type Fuse Link 100A 500VAC NH2 39.5mm 120kA For: NH2 Bases and Disconnects

Product Code: NHG2-100

  • Rated for 100 A, 500 VAC
  • Compatible with NH2 bases
  • Compact body size: 39.5 mm
  • High breaking capacity: 120 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
NH
Application
General purpose cable and line protection

Electrical

Utilization Category
gG
Breaking Capacity
120kA
Rated Current (In)
100A
Rated Voltage (Ur)
500V AC / 250V DC

Mechanical

Body Style
Square body
Indicators
Double indicator
Material
Body:Ceramic, silver-plated copper contacts
Size Code
NH2
Connection/Termination
Knife blade

Dimensions & Physical Data

Length
150mm (approx.)
Weight
0.42kg (Approx.)
Width
39.5mm (approx.)

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 and -2, VDE 0636 Part 201
