Mersen NHG1-315 Blade Type Fuse Link 315A 500VAC NH1 39.5mm 120kA

Product Code: NHG1-315

  • Rated current of 315 A for robust applications
  • Supports up to 500 VAC systems
  • High breaking capacity of 120 kA
  • Compact NH1 size with 39.5 mm body
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
NH
Application
General purpose cable and line protection

Electrical

Utilization Category
gG
Breaking Capacity
120kA
Rated Current (In)
315A
Rated Voltage (Ur)
500V AC / 250V DC

Mechanical

Body Style
Square body
Indicators
Double indicator
Material
Body:Ceramic, silver-plated copper contacts
Size Code
NH1
Connection/Termination
Knife blade

Dimensions & Physical Data

Length
135mm (approx.)
Weight
0.42kg (Approx.)
Width
39.5mm (approx.)

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 and -2, VDE 0636 Part 201
