Mersen NHG1-063 Blade Type Fuse Link 63A 500VAC NH1 29.5mm 120kA For: NH1 Bases and Disconnects

Product Code: NHG1-063

  • NH DIN Blade for efficient circuit protection
  • Rated for 63 A and 500 VAC applications
  • Compatible with NH1 Bases and Disconnects
  • Compact body size of 29.5 mm
  • High breaking capacity of 120 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
NH
Application
General purpose cable and line protection

Electrical

Utilization Category
gG
Breaking Capacity
120kA
Rated Current (In)
63A
Rated Voltage (Ur)
500V AC / 250V DC

Mechanical

Body Style
Square body
Indicators
Double indicator
Material
Body:Ceramic, silver-plated copper contacts
Size Code
NH1
Connection/Termination
Knife blade

Dimensions & Physical Data

Depth
64mm (approx.)
Length
135mm (approx.)
Weight
0.28kg (Approx.)
Width
30mm (approx.)

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 and -2, VDE 0636 Part 201
