Mersen NHG00-080 Blade Type Fuse Link 80A 500VAC NH000 20.8mm 120kA For: 00 Bases and Disconnects

Product Code: NHG00-080

  • Rated for 80 A and 500 VAC
  • Compatible with 00 bases
  • Compact body size of 20.8 mm
  • High breaking capacity of 120 kA
  • NH000 fuse size
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
NH
Application
General purpose cable and line protection

Electrical

Utilization Category
gG
Breaking Capacity
120kA
Rated Current (In)
80A
Rated Voltage (Ur)
500V AC / 250V DC

Mechanical

Body Style
Square body
Indicators
Double indicator
Material
Body:Ceramic, silver-plated copper contacts
Size Code
NH000
Connection/Termination
Knife blade

Dimensions & Physical Data

Depth
52.5mm
Length
78.5mm
Weight
0.13kg (Approx.)
Width
21mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 and -2, VDE 0636 Part 201

Documents

IPD Product Catalogue V17
