Mersen NH2PV-250 Photovoltaic Fuse 250 A 1000VDC Plain Blade Terminal

Product Code: NH2PV-250

  • Handles up to 250 A at 1000 VDC
  • Compact width of 51 mm
  • Easy clip mounting system
  • Silver plated copper terminals
  • High interrupt rating of 50 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Photovoltaic Fuse - Link
Brand
Mersen
Series
HelioProtection HP10NH
Application
All photovoltaic applications, Inverter DC input protection, Re-combiner applications

Electrical

Utilization Category
gPV
Breaking Capacity
50kA DC
Rated Current (In)
250A
Rated Voltage (Ur)
1000V DC

Mechanical

Body Style
Square body
Indicators
without indicator
Material
Body: Ceramic, Terminal: Silver-Plated Copper
Size Code
NH2
Connection/Termination
Plain blades

Dimensions & Physical Data

Depth
60mm
Length
150mm
Weight
0.6kg (Approx.)
Width
51mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-6; UL 2579
