Mersen HP15P32 Photovoltaic Fuse 32 A 1500VDC gPV 20mm Dia x 65mm Fuse Ferrule Terminal

Product Code: HP15P32

  • Rated for 32 A, 1500 VDC
  • UL, CSA, IEC & UKCA approved
  • High interrupt rating of 50 kA
  • Compact 65 mm length design
  • Tin-plated copper terminals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Photovoltaic Fuse - Link
Brand
Mersen
Series
HelioProtection HP15Pxx
Application
PV string / array protection, combiner boxes, inverters and battery charge controllers

Electrical

Utilization Category
gPV
Breaking Capacity
50kA DC
Rated Current (In)
32A
Rated Voltage (Ur)
1500V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body:GMG, Terminal: Tin-Plated Copper
Mounting
Clip
Size Code
20 x 65
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
65mm
Weight
0.0499kg (Approx.)
Width
Ø 20mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-19; CSA C22.2; IEC 60269-6; UKCA
