Mersen HP15M15 Photovoltaic Fuse 15 A 1500VDC gPV 10mm Dia x 85mm Fuse Ferrule Terminal

Product Code: HP15M15

  • Rated for 15 A, 1500 VDC applications
  • UL Listed, IEC 60269-6 compliant
  • High interrupt rating of 50 kA
  • Tin plated copper ferrule terminals
  • Compact design with 85 mm length
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Photovoltaic Fuse - Link
Brand
Mersen
Series
HelioProtection HP15MxxR
Application
PV string / array protection, combiner boxes, inverters and battery charge controllers

Electrical

Utilization Category
gPV
Breaking Capacity
50kA DC
Rated Current (In)
15A
Rated Voltage (Ur)
1500V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body:GMG, Terminal: Tin-Plated Copper
Mounting
Clip
Size Code
10 x 85
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
85mm
Weight
0.0136kg (Approx.)
Width
Ø 10mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-19; CSA C22.2; IEC 60269-6
