Mersen HP10M8 Photovoltaic Fuse 8 A 1000VDC gPV 10mm Dia x 38mm Fuse Ferrule Terminal

Product Code: HP10M8

  • Rated for 1000 VDC, ideal for high voltage systems
  • UL Listed and CSA Approved for assured safety
  • Compact design with a length of 38 mm
  • Ferrule terminal type ensures secure connections
  • High interrupt rating of 50 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Photovoltaic Fuse - Link
Brand
Mersen
Series
HelioProtection HP10M
Application
PV string / array protection, combiner boxes, inverters and battery charge controllers

Electrical

Utilization Category
gPV
Breaking Capacity
50 kA DC
Rated Current (In)
8 A
Rated Voltage (Ur)
1000 V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body:GMG, Terminal: Tin-Plated Copper
Mounting
Clip
Size Code
10 x 38
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
38 mm
Weight
0.0091 kg (Approx.)
Width
Ø 10 mm

Safety, Standards & Compliance

Standards and Approvals
UL 2579; CSA C22.2; IEC 60269-6
