MERSEN FUSE LINK 80A 690V gS 000 DIN FOR SEMICONDUCTOR PROTECTION USE NH FUSE BASES P322059

Product Code: P322059

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High - Speed Fuse - Link
Brand
Mersen
Application
Semiconductor and cable protection using NH fuse bases

Electrical

Suitable For
NH fuse bases
Utilization Category
gS
Breaking Capacity
120kA AC
Rated Current (In)
80A
Rated Voltage (Ur)
690V AC
Speed Class
Ultra fast acting

Mechanical

Body Style
NH DIN body
Indicators
Without indicator
Material
Ceramic body, silver-plated contacts
Mounting
NH fuse base
Size Code
NH000
Connection/Termination
NH knife blades

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-4; DIN 43620

Documents

IPD Product Catalogue V17
