MERSEN FUSE LINK 80A 690V 22*58MM FR22GR69V80T WITH TRIP INDICATOR 22F80 22GR80 E1018628

Product Code: E1018628

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Application
Power semiconductor protection

Electrical

Utilization Category
gR
Breaking Capacity
160 kA
Rated Current
80 A
Rated Voltage
690 V AC
Speed Class
gR

Mechanical

Body Style
Cylindrical
Indicators
With striker / trip-indicator
Material
Body:Ceramic, Terminal: Silver plated copper
Mounting
Clip
Size Code
22 x 58
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
58 mm
Weight
0.060 kg (Approx.)
Width
Ø 22.2 mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -4; UL 248-13; CCC GB 13539.4; RoHS

Documents

IPD Product Catalogue V17
