MERSEN FUSE LINK 60A 250V OFFSET TAG SINGLE BODY SEMICONDUCTOR W076655

Product Code: W076655

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High - Speed BS88 Fuse - Link
Brand
Mersen
Series
aR
Application
Semiconductor protection

Electrical

Utilization Category
aR
Breaking Capacity
200kA AC
Rated Current (In)
60A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
250V AC
Speed Class
aR

Mechanical

Body Style
Offset tag single body
Indicators
Without indicator
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
17 x 27
Connection/Termination
Offset tag

Dimensions & Physical Data

Length
60mm overall
Width
Ø 17mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-4; BS88
