MERSEN FUSE LINK 50A 690V 22*58MM FR22GR69V50T WITH TRIP INDICATOR 22F50 22GR50 C1018626

Product Code: C1018626

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Application
Small inverters, UPS systems and motor drives

Electrical

Utilization Category
gR
Breaking Capacity
160kA AC
Rated Current (In)
50A
Rated Voltage (Ur)
690V AC
Speed Class
High speed / fast acting

Mechanical

Body Style
Cylindrical
Indicators
With striker
Material
Ceramic body, silver fuse elements, silver-plated copper end caps
Mounting
22x58 fuse holder
Size Code
22 x 58
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
58mm
Weight
0.06kg (Approx.)
Width
Ø 22.2mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-4; UL 248-13; CCC GB 13539.4
