MERSEN FUSE LINK 4A 690V gR 14*51MM FOR SEMICONDUCTOR PROTECTION WITH TRIP INDICATOR 14F04 E1017179

Product Code: E1017179

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High - Speed Fuse - Link
Brand
Mersen
Application
Semiconductor protection for power electronics

Electrical

Utilization Category
gR
Breaking Capacity
200 kA
Rated Current (In)
0.166667
Rated Voltage (Ur)
690 V AC
Speed Class
Ultra fast acting

Mechanical

Body Style
Cylindrical
Fixing Centres
51 mm
Indicators
Trip indicator
Material
Ceramic body, silver-plated copper contacts
Mounting
Ferrule
Size Code
14 x 51
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
51 mm
Weight
0.025 kg (Approx.)
Width
Ø 14 mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-4

Documents

IPD Product Catalogue V17
