MERSEN FUSE LINK 4A 690V gR 10*38MM FOR SEMI CONDUCTOR PROTECTION USE CMS101 BASE 10F04 10GR04 W1014572

Product Code: W1014572

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High - Speed Fuse - Link
Brand
Mersen
Series
gR
Application
Semiconductor protection

Electrical

Utilization Category
gR
Breaking Capacity
200 kA AC
Rated Current (In)
0.166667
Rated Frequency
50/60 Hz
Rated Voltage (Ur)
690 V AC
Speed Class
gR

Mechanical

Body Style
Cylindrical
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
10 x 38
Connection/Termination
Ferrule end caps
Fuse Holder
CMS101

Dimensions & Physical Data

Length
38 mm
Weight
0.008 kg (Approx.)
Width
Ø 10 mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-4
