MERSEN FUSE LINK 45A 690V OFFSET TAG SINGLE BODY SEMICONDUCTOR N075889

Product Code: N075889

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High - Speed BS88 Fuse - Link
Brand
Mersen
Application
Semiconductor protection for power electronic systems.

Electrical

Utilization Category
gR
Breaking Capacity
200kA AC
Rated Current (In)
45A
Rated Voltage (Ur)
690V AC
Speed Class
Ultra fast acting

Mechanical

Body Style
Offset tag single body
Indicators
Without indicator
Material
Ceramic body, copper terminals
Mounting
Bolted offset tag / L brackets
Size Code
17 x 49
Connection/Termination
Offset tag blades / L brackets

Dimensions & Physical Data

Length
77.2mm overall
Weight
0.039kg (Approx.)
Width
Ø 18.5mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -4; BS88-4

Documents

IPD Product Catalogue V17
