MERSEN FUSE LINK 150A 690V OFFSET TAG FOR SEMICONDUCTOR PROTECTION Q097166

Product Code: Q097166

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High - Speed BS88 Fuse - Link
Brand
Mersen
Application
Semiconductor protection for power electronic systems.

Electrical

Utilization Category
aR
Breaking Capacity
200kA AC
Rated Current (In)
150A
Rated Voltage (Ur)
690V AC
Speed Class
Ultra fast acting

Mechanical

Body Style
Offset / bolt tag body
Indicators
Without indicator
Material
Ceramic body, silver-plated contacts
Mounting
Bolted tags
Size Code
36 x 55
Connection/Termination
Bolt tag terminals

Dimensions & Physical Data

Length
110mm overall
Width
Ø 37.3mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-4; BS88

Documents

IPD Product Catalogue V17
