MERSEN FUSE LINK 1100A 110MM FIXING FOR SEMICONDUCTOR PROTECTION BODY SIZE 33, 660V A300265

Product Code: A300265

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Semiconductor Fuse Link - PSC
Brand
Mersen

Electrical

Breaking Capacity
200kA
Rated Current (In)
1100A
Rated Voltage (Ur)
690V
Speed Class
aR

Mechanical

Body Style
Square Body
Indicators
With striker type
Material
Body: Ceramic, Terminal:Silver-Plated Copper
Size Code
Size 33
Connection/Termination
DIN 110 Blades

Dimensions & Physical Data

Length
134.6mm
Weight
0.874kg (Approx.)
Width
73mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269.4, ROHS Compliant

Documents

IPD Product Catalogue V17
