Mersen ATM25 Fast-Acting Midget Fuse 25A 600VAC/DC 0.41 in Dia 1.5 in L 100kA Interrupt Ferrule

Product Code: ATM25

  • Rated for 25 A, 600 VAC/VDC
  • Compact size: 1.5 in length
  • High interrupt rating: 100 kA
  • Clip mounting for easy installation
  • Tin plated copper terminals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Midget Fast - Acting Fuse
Brand
Mersen
Series
ATM
Application
Supplemental protection of circuits up to 600 V AC / DC, small motors, transformers and control circuits

Electrical

Breaking Capacity
100kA
Rated Current (In)
25A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC/DC
Speed Class
Fast acting

Mechanical

Body Style
Cylindrical / ferrule
Indicators
without indicator
Material
Glass body; metal end caps
Mounting
Fuse holder / clips
Size Code
10 x 38
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
38mm
Weight
0.0064kg
Width
Ø 10mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-14; CSA C22.2 No. 248.14

Documents

IPD Product Catalogue V17
