Mersen AJT600 Power Fuse 600A 600/500VAC/DC Class J 63.5mm Dia x 203.2mm L Blade Terminal Class J 200kA

Product Code: AJT600

  • 600 A rated current for high power demands
  • Supports 600/500 VAC/VDC applications
  • Clip or bolted mounting flexibility
  • High breaking capacity of 200 kA
  • Durable GMG body and insulation material
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
AJT
Application
Motor circuits, mains, feeders, branch circuits, lighting / heating loads, transformers and control panels

Electrical

Utilization Category
Class J
Breaking Capacity
200kA AC
Rated Current (In)
600A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 400V DC
Speed Class
Time delay

Mechanical

Body Style
Blade fuse
Fixing Centres
152mm
Indicators
Non-indicating; SmartSpot indicator version available
Material
Fiberglass body; high-grade silica filler; metal end caps
Mounting
Fuse holder / fuse block
Size Code
Class J 401–600 A
Connection/Termination
Blade terminals

Dimensions & Physical Data

Height
203mm
Width
64mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-8; CSA C22.2 No. 248.8; IEC 60269-2-1
