Mersen AJT50 Power Fuse 50A 600/400VAC/DC Class J 27mm Dia x 60.5mm L Ferrule Terminal Class J 200kA

Product Code: AJT50

  • UL North American fuse, 50 A rated
  • Rated Voltage: 600/400 VAC/VDC
  • High breaking capacity of 200 kA
  • Compact size: 27 mm Dia x 60.5 mm L
  • Ferrule terminals with tin-plated copper
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
AJT
Application
Motor circuits, mains, feeders, branch circuits, lighting / heating loads, transformers and control panels

Electrical

Utilization Category
Class J
Breaking Capacity
200kA AC
Rated Current (In)
50A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 400V DC
Speed Class
Time delay

Mechanical

Body Style
Cylindrical / ferrule
Indicators
Non-indicating; SmartSpot indicator version available
Material
Fiberglass body; high-grade silica filler; metal end caps
Mounting
Fuse holder / fuse block
Size Code
27 x 60
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Height
60mm
Weight
0.044kg
Width
Ø 27mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-8; CSA C22.2 No. 248.8; IEC 60269-2-1

Documents

IPD Product Catalogue V17
