Mersen AJT350 Power Fuse 350A 600/500VAC/DC Class J 54mm Dia x 181.1mm L Blade Terminal Class J 200kA

Product Code: AJT350

  • High 350 A rated current capacity
  • Versatile 600/500 VAC/VDC rating
  • Robust 200 kA breaking capacity
  • Convenient clip or bolted mounting
  • Durable GMG body and insulation material
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
AJT
Application
Protection at all levels of power distribution

Electrical

Breaking Capacity
300kA
Rated Current (In)
350A
Rated Voltage (Ur)
600V AC / 400V DC
Speed Class
Time Delay/Class J

Mechanical

Body Style
Bolted Tag
Fixing Centres
133mm
Material
Body: GMG, Terminal:Brass

Dimensions & Physical Data

Length
181.1mm
Weight
0.81kg (Approx.)
Width
Ø 54mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-2-1

Documents

IPD Product Catalogue V17
