Mersen AJT175 Power Fuse 175A 600/500VAC/DC Class J 41.3mm Dia x 146mm L Blade Terminal Class J 200kA

Product Code: AJT175

  • Rated for 175 A current
  • Voltage capacity: 600/500 VAC/VDC
  • High breaking capacity of 200 kA
  • Mounts via clip or bolt
  • Blade terminal type
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
AJT
Application
Protection at all levels of power distribution

Electrical

Breaking Capacity
300kA
Rated Current (In)
175A
Rated Voltage (Ur)
600V AC / 400V DC
Speed Class
Time Delay/Class J

Mechanical

Body Style
Bolted Tag
Fixing Centres
111mm
Material
Body: GMG, Terminal:Brass

Dimensions & Physical Data

Length
146mm
Weight
0.35kg (Approx.)
Width
Ø 41.3mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-2-1
