Mersen AG3 Power Fuse 3A 600VAC Class G Ferrule 10mm x 33mm 100kA Interrupt Time Delay

Product Code: AG3

  • Rated 3 A, 600 VAC for reliable performance
  • Compact 10 mm x 33 mm body size
  • High interrupt rating of 100 kA
  • Class G fuse with ferrule style design
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
AG

Electrical

Breaking Capacity
100 kA
Rated Current (In)
0.125
Rated Voltage (Ur)
600 V AC
Speed Class
Time Delay

Mechanical

Body Style
Cylindrical
Material
Body: Fiberglass, End cap: tin plated copper
Size Code
AG

Dimensions & Physical Data

Length
33.3 mm
Weight
0.0073 kg (Approx.)
Width
Ø 10.3 mm

Safety, Standards & Compliance

Standards and Approvals
CSA Certified-C22.2 No. 248.5
