Mersen AG20 Power Fuse 20A 600VAC Class G Ferrule 10mm x 33mm 100kA Interrupt Time Delay

Product Code: AG20

  • Rated for 20 A, 600 VAC
  • Compact size: 10 mm x 33 mm
  • High interrupt capacity: 100 kA
  • Class G ferrule body design
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
AG

Electrical

Breaking Capacity
100kA
Rated Current (In)
20A
Rated Voltage (Ur)
600V AC
Speed Class
Time Delay

Mechanical

Body Style
Cylindrical
Material
Body: Fiberglass, End cap: tin plated copper
Size Code
AG

Dimensions & Physical Data

Length
33.3mm
Weight
0.0073kg (Approx.)
Width
Ø 10.3mm

Safety, Standards & Compliance

Standards and Approvals
CSA Certified-C22.2 No. 248.5
