Mersen A4J90 Power Fuse 90A 600/300VAC/DC Class J 1.06 in Dia x 4.63 in L 200kA Fast Acting

Product Code: A4J90

  • Rated for 90 A, 600/300 VAC/VDC
  • High breaking capacity of 200 kA
  • Compact size: 1.06 in Dia x 4.63 in L
  • Easy clip mounting system
  • Durable GMG body and insulation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
North American Fuse Link
Application
Protection at all levels of power distribution

Electrical

Breaking Capacity
200kA
Rated Current (In)
90A
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast-Acting

Mechanical

Body Style
Bolted tag
Material
Terminal: Tin platted copper, Fiberglass body

Dimensions & Physical Data

Length
67mm
Width
Ø 29mm

Safety, Standards & Compliance

Standards and Approvals
IEC 269-2-1, DC listed to UL 248, ROHS Compliant
