Mersen A4J80 Power Fuse 80A 600/300VAC/DC Class J 1.06 in Dia x 4.63 in L 200kA Fast Acting

Product Code: A4J80

  • Rated for 80 A current
  • Handles up to 600/300 VAC/VDC
  • High breaking capacity: 200 kA
  • Compact size: 1.06 in Dia x 4.63 in L
  • Clip mounting for easy installation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
North American Fuse Link
Brand
Mersen
Application
Protection at all levels of power distribution

Electrical

Breaking Capacity
200kA
Rated Current (In)
80A
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast-Acting

Mechanical

Body Style
Bolted tag
Material
Terminal: Tin platted copper, Fiberglass body

Dimensions & Physical Data

Length
67mm
Width
Ø 29mm

Safety, Standards & Compliance

Standards and Approvals
IEC 269-2-1, DC listed to UL 248, ROHS Compliant
