Mersen A4J70 Power Fuse 70A 600/300VAC/DC Class J 1.06 in Dia x 4.63 in L 200kA Fast Acting

Product Code: A4J70

  • Rated current of 70 A
  • Voltage up to 600/300 VAC/VDC
  • High breaking capacity of 200 kA
  • Blade terminal with silver-plated copper
  • Compact size: 1.06 in Dia x 4.63 in L
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
North American Fuse Link
Brand
Mersen
Application
Protection at all levels of power distribution

Electrical

Breaking Capacity
200kA
Rated Current (In)
70A
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast-Acting

Mechanical

Body Style
Bolted tag
Material
Terminal: Tin platted copper, Fiberglass body

Dimensions & Physical Data

Length
67mm
Width
Ø 29mm

Safety, Standards & Compliance

Standards and Approvals
IEC 269-2-1, DC listed to UL 248, ROHS Compliant
