Mersen A4J450 Power Fuse 450A 600/300VAC/DC Class J 2.5 in Dia x 8 in L 200kA Fast Acting

Product Code: A4J450

  • Rated current of 450 A
  • Voltage rating: 600/300 VAC/VDC
  • High breaking capacity: 200 kA
  • Compact size: 2.5 in Dia x 8 in L
  • Durable GMG body and insulation material
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
North American Fuse Link
Brand
Mersen
Application
Protection at all levels of power distribution

Electrical

Breaking Capacity
200kA
Rated Current (In)
450A
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast-Acting

Mechanical

Body Style
Bolted tag
Material
Terminal: Tin platted copper, Fiberglass body

Dimensions & Physical Data

Length
95mm
Width
Ø 64mm

Safety, Standards & Compliance

Standards and Approvals
IEC 269-2-1, DC listed to UL 248, ROHS Compliant
