Mersen A4J35 Power Fuse 35A 600/300VAC/DC Class J 1.06 in Dia x 2.38 in L 200kA Fast Acting

Product Code: A4J35

  • Rated for 35 A current
  • Voltage up to 600/300 VAC/VDC
  • High breaking capacity of 200 kA
  • Clip mounting for easy installation
  • Durable poly tube body material
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
A4J
Application
Capacitors, distribution boards, busways, feeders, breakers, and load circuits

Electrical

Utilization Category
Class J
Breaking Capacity
200kA AC / 100kA DC
Rated Current (In)
35A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast-Acting

Mechanical

Body Style
Cylindrical
Indicators
No indicator
Material
Body: Fiberglass, Terminal: Silver plated copper
Mounting
Clip
Size Code
Class J
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
60mm
Weight
0.077kg (Approx.)
Width
Ø27mm

Safety, Standards & Compliance

Standards and Approvals
UL Listed to UL 248-8; CSA C22.2 No. 248.8; DC Listed to UL 248; IEC 269-2-1
