Mersen A4BQ700 Time Delay Current-Limiting Fuse 700A 600/500VAC/DC 63mmDia 97mm L Class L 200kA Bolt-In

Product Code: A4BQ700

  • 700 A current rating for robust performance
  • 600/500 VAC/VDC voltage capacity
  • High breaking capacity of 200 kA
  • Bolt-in mounting for secure installation
  • Silver plated copper terminals ensure conductivity
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
A4BQ
Application
Main / feeder circuits, motors, lighting, heating, general loads, breaker backup, and DC systems.

Electrical

Utilization Category
Class L
Breaking Capacity
200kA AC / 100kA DC
Rated Current (In)
700A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 500V DC
Speed Class
Time Delay

Mechanical

Body Style
Cylindrical
Indicators
No indicator
Material
Body: Fiberglass, Element: Pure silver
Mounting
Bolt-in
Size Code
Class L
Connection/Termination
Bolted blade terminals

Dimensions & Physical Data

Length
219mm
Weight
1.71kg (Approx.)
Width
Ø 63mm

Safety, Standards & Compliance

Standards and Approvals
UL Listed to UL 248-10; DC Listed to UL 248; CSA C22.2 No. 248.10
