Mersen A4BQ5000 Time Delay Current-Limiting Fuse 5000A 600VAC 159mmDia 97mm L Class L 200kA Bolt-In

Product Code: A4BQ5000

  • Rated 5000 A for high current applications
  • Supports up to 600 VAC for versatile use
  • High breaking capacity of 200 kA
  • Bolt-in mounting for secure installation
  • Silver plated copper terminals ensure conductivity
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
A4BQ
Application
Main / feeder circuits, motors, lighting, heating, general loads, breaker backup, and DC systems.

Electrical

Utilization Category
Class L
Breaking Capacity
200kA AC / 100kA DC
Rated Current (In)
5000A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 500V DC
Speed Class
Time Delay

Mechanical

Body Style
Cylindrical
Indicators
No indicator
Material
Body: Fiberglass, Element: Pure silver
Mounting
Bolt-in
Size Code
Class L
Connection/Termination
Bolted blade terminals

Dimensions & Physical Data

Depth
88mm
Length
273mm
Weight
14.29kg (Approx.)
Width
159mm

Safety, Standards & Compliance

Standards and Approvals
UL Listed to UL 248-10; DC Listed to UL 248; CSA C22.2 No. 248.10
