Mersen A4BQ3500 Time Delay Current-Limiting Fuse 3500A 600VAC 146mmDia 97mm L Class L 200kA Bolt-In

Product Code: A4BQ3500

  • Rated for 3500 A current
  • Handles up to 600 VAC voltage
  • Bolt-in mounting for secure installation
  • High breaking capacity of 200 kA
  • Silver plated copper terminals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
A4BQ
Application
Mains, feeders, large motors, lighting / heating loads and circuit breaker backup

Electrical

Utilization Category
Class L
Breaking Capacity
200kA AC
Rated Current (In)
3500A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC
Speed Class
Time delay

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Fiberglass body, silver-plated copper blades
Mounting
Holder or bolted blade mounting
Connection/Termination
Knife blade

Dimensions & Physical Data

Length
273mm
Weight
1.133kg (Approx.)
Width
Ø 146mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-10; CSA C22.2 No. 248.10
