Mersen A4BQ2500 Time Delay Current-Limiting Fuse 2500A 600/500VAC/DC 114mmDia 97mm L Class L 200kA Bolt-In

Product Code: A4BQ2500

  • Rated for 2500 A and 600/500 VAC/VDC
  • High breaking capacity of 200 kA
  • Bolt-in mounting for secure installation
  • Silver plated copper terminals ensure conductivity
  • Durable GMG body and insulation materials
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
A4BQ
Application
Mains, feeders, large motors, lighting / heating loads, circuit breaker backup, UPS DC links and battery disconnects

Electrical

Utilization Category
Class L
Breaking Capacity
200kA AC / 100kA DC
Rated Current (In)
2500A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 500V DC
Speed Class
Time delay

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Fiberglass body, silver-plated copper blades
Mounting
Holder or bolted blade mounting
Connection/Termination
Knife blade

Dimensions & Physical Data

Length
273mm
Weight
6.22kg (Approx.)
Width
Ø 114mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-10; CSA C22.2 No. 248.10
