Mersen A4BQ1500 Time Delay Current-Limiting Fuse 1500A 600/500VAC/DC 76mmDia 97mm L Class L 200kA Bolt-In

Product Code: A4BQ1500

  • Rated for 1500 A current
  • Handles up to 600/500 VAC/VDC
  • High breaking capacity of 200 kA
  • Bolt-in mounting for easy install
  • Silver plated copper terminals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
A4BQ
Application
Mains, feeders, large motors, lighting / heating loads, circuit breaker backup, UPS DC links and battery disconnects

Electrical

Utilization Category
Class L
Breaking Capacity
200kA AC / 100kA DC
Rated Current (In)
1500A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 500V DC
Speed Class
Time delay

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Fiberglass body, silver-plated copper blades
Mounting
Holder or bolted blade mounting
Connection/Termination
Knife blade

Dimensions & Physical Data

Length
273mm
Weight
2.7079kg (Approx.)
Width
Ø 76mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-10; CSA C22.2 No. 248.10

Documents

IPD Product Catalogue V17
