Mersen 45DB120V31.5P HV Fuse-Link 31.5A 12 kV 56mm Dia x 292mm L Cylindrical 63kA Ceramic Medium Striker Striker 80N

Product Code: 45DB120V31.5P

  • Rated for 31.5 A and 12 kV applications
  • High breaking capacity of 63 kA
  • Durable ceramic body construction
  • Features a striker indicator with 80N force
  • Silver plated copper contacts for reliable connections
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN HV Back - Up Fuse
Brand
Mersen
Application
HV Transformer protection

Electrical

Breaking Capacity
63kA
Rated Current (In)
31.5A
Rated Voltage (Ur)
6 / 12kV

Mechanical

Body Style
Cylindrical
Indicators
Medium striker 80 N / 30 mm
Material
Fuse element: pure silver, Caps: Copper coated with silver, Body: pure silver
Connection/Termination
DIN clip-in (end-cap type)

Dimensions & Physical Data

Weight
1.7kg (Approx.)

Safety, Standards & Compliance

Standards and Approvals
IEC 60282-1, VDE 0670 part 4, DIN 43625
