Mersen 22G80 Fuse Link 80A 690VAC Cylindrical Ferrule 22mm Dia x 58mm L 120kA Ceramic gG

Product Code: 22G80

  • Rated for 80A current
  • Handles up to 690VAC
  • Compact size: 22mm dia x 58mm length
  • High breaking capacity of 120kA
  • Durable ceramic construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ferrule fuse-links
Brand
Mersen
Application
Industrial application and electrical distribution circuits.

Electrical

Utilization Category
gG
Breaking Capacity
120 kA AC / 100 kA DC
Rated Current
80 A
Rated Voltage
690 V AC / 250 V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
22 x 58
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
58 mm
Weight
0.054 kg (Approx.)
Width
Ø 22.2 mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -2
