Mersen 22G32 Fuse Link 32A 690VAC Cylindrical Ferrule 22mm Dia x 58mm L 120kA Ceramic gG

Product Code: 22G32

  • DIN Ferrule with 32 A rated current
  • Supports up to 690 VAC voltage
  • High breaking capacity of 120 kA
  • Durable ceramic material construction
  • Compact cylindrical ferrule design
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ferrule Fuse - Links
Brand
Mersen
Application
Industrial application and electrical distribution circuits.

Electrical

Utilization Category
gG
Breaking Capacity
120kA AC / 100kA DC
Rated Current (In)
32A
Rated Voltage (Ur)
690V AC / 250V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
22 x 58
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
58mm
Weight
0.054kg (Approx.)
Width
Ø 22.2mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -2
