Mersen 14G02 Fuse Link 2A 690VAC Cylindrical Ferrule 14mm Dia x 51mm L 120kA Ceramic gG

Product Code: 14G02

  • DIN Ferrule with 2A rated current
  • Supports up to 690 VAC
  • Compact size: 14mm diameter, 51mm length
  • High breaking capacity of 120kA
  • Durable ceramic cylindrical body
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ferrule Fuse - Links
Brand
Mersen
Application
Industrial application and electrical distribution circuits.

Electrical

Utilization Category
gG
Breaking Capacity
120 kA AC / 100 kA DC
Rated Current (In)
0.083333
Rated Voltage (Ur)
690 V AC / 250 V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
14 x 51
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
51 mm
Weight
0.021 kg (Approx.)
Width
Ø 14.3 mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -2

Documents

IPD Product Catalogue V17
