Mersen 10G25 Fuse Link 25A 500VAC Cylindrical Ferrule 10mm Dia x 38mm L 120kA Ceramic gG

Product Code: 10G25

  • Handles up to 25 A current
  • Operates at 500 VAC voltage
  • Compact size: 10 mm Dia x 38 mm L
  • High breaking capacity of 120 kA
  • Durable ceramic construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ferrule Fuse - Links
Brand
Mersen
Application
Industrial application and electrical distribution circuits.

Electrical

Utilization Category
gG
Breaking Capacity
120kA AC / 100kA DC
Rated Current (In)
25A
Rated Voltage (Ur)
500V AC / 250V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
10 x 38
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
38mm
Weight
0.008kg (Approx.)
Width
Ø 10.3mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -2
