Mersen 10G16 Fuse Link 16A 500VAC Cylindrical Ferrule 10mm Dia x 38mm L 120kA Ceramic gG

Product Code: 10G16

  • Rated for 16 A and 500 VAC
  • Compact size: 10 mm Dia x 38 mm L
  • High breaking capacity of 120 kA
  • Durable ceramic material construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ferrule Fuse - Links
Brand
Mersen
Application
Industrial application and electrical distribution circuits.

Electrical

Utilization Category
gG
Breaking Capacity
120kA AC / 100kA DC
Rated Current (In)
16A
Rated Voltage (Ur)
500V AC / 250V DC

Mechanical

Body Style
Cylindrical
Indicators
without indicator
Material
Body: Ceramic, Contact: Silver plated copper
Size Code
10 x 38
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
38mm
Weight
0.008kg (Approx.)
Width
Ø 10.3mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269-1 & -2

Documents

IPD Product Catalogue V17
