Mersen 10G005 Fuse Link 0.5A 500VAC Cylindrical Ferrule 10mm Dia x 38mm L 120kA Ceramic gG

Product Code: 10G005

  • Rated for 0.5 A current
  • Handles up to 500 VAC
  • Compact size: 10 mm Dia x 38 mm L
  • High breaking capacity of 120 kA
  • Durable ceramic construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
Ferrule fuse-links 10×38 gG
Application
Protection of cables, motors, LV networks, industrial distribution circuits

Electrical

Utilization Category
gG
Breaking Capacity
up to 120 kA
Fuse Class
IEC cylindrical (gG)
Rated Current (In)
0.5A
Rated Voltage (Ur)
500V AC

Mechanical

Body Style
Cylindrical / cartridge
Contact Material
Silver-plated copper
Indicators
without indicator
Material
Ceramic body
Mounting
Holder / clip mounting
Top Cap Diameter
~10mm

Dimensions & Physical Data

Size
Ø10.3 mm × 38 mm

Documents

IPD Product Catalogue V17
