IPD W66US550 Unswitched Socket 5 Round-Pin 3-Ph 50A 500VAC/DC IP66 Polycarbonate

Product Code: W66US550

  • 50A, 500V AC/DC rated socket
  • Durable polycarbonate construction
  • IP66 protection against dust and water
  • Includes (1) M32 and (2) M25 gland entries
  • Round pin configuration
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Unwitched Socket
Brand
IPD
Series
W66

Electrical

No. of Phases
3 phase
Rated Current (In)
50A
Rated Voltage (Ur)
500V
No. of Switching Poles
4
With Neutral Conductor
Yes

Mechanical

Colour
Light Grey
Gland Entries
1 x M32, 2 x M25
Material
Polycarbonate
No. of Pins
5 Pin
Pin Type
Round
Max. Cable Size
16 mm²

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZ 3123

Documents

IPD Product Catalogue V17
