IPD W66US540 Unswitched Socket 5 Round-Pin 3-Ph 40A 500VAC/DC IP66 Polycarbonate

Product Code: W66US540

  • 40 A socket with IP66 protection
  • Supports 500 VAC/VDC applications
  • Durable polycarbonate construction
  • Includes back box for easy installation
  • Multiple gland entries: M32 and M25
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Unwitched Socket
Brand
IPD
Series
W66

Electrical

No. of Phases
3 phase
Rated Current (In)
40A
Rated Voltage (Ur)
500V
No. of Switching Poles
4
With Neutral Conductor
Yes

Mechanical

Colour
Light Grey
Gland Entries
1 x M32, 2 x M25
Material
Polycarbonate
No. of Pins
5 Pin
Pin Type
Round
Max. Cable Size
16 mm²

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZ 3123

Documents

IPD Product Catalogue V17
