IPD W66US510LB Unswitched Socket 5 Round-Pin 3-Ph 10A 500VAC/DC IP66 Polycarbonate

Product Code: W66US510LB

  • Durable polycarbonate construction
  • IP66 rating for robust protection
  • Suitable for 500 VAC/VDC applications
  • Accommodates cable up to 6 sq-mm
  • Includes M32 and M25 gland entries
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Unwitched Socket
Brand
IPD
Series
W66

Electrical

No. of Phases
3 phase
Rated Current (In)
0.416667
Rated Voltage (Ur)
500 V
No. of Switching Poles
4
With Neutral Conductor
Yes

Mechanical

Colour
Light Grey
Gland Entries
1 x M32, 2 x M25
Material
Polycarbonate
No. of Pins
5 Pin
Pin Type
Round
Max. Cable Size
6 mm²
With Base
Base not included

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZ 3123

Documents

IPD Product Catalogue V17
