IPD W66US440 Unswitched Socket 4 Round-Pin 3-Ph 40A 500VAC/DC IP66 Polycarbonate

Product Code: W66US440

  • 40 A socket for high power applications
  • Compact size: 101 x 101 x 91 mm
  • Durable polycarbonate construction
  • IP66 rated for dust and water protection
  • Compatible with AS3123 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Unwitched Socket
Brand
IPD
Series
W66

Electrical

No. of Phases
3 phase
Rated Current (In)
40A
Rated Voltage (Ur)
500V
No. of Switching Poles
3
With Neutral Conductor
Yes

Mechanical

Colour
Light Grey
Gland Entries
1 x M32, 2 x M25
Material
Polycarbonate
No. of Pins
4 Pin
Pin Type
Round
Max. Cable Size
16 mm²

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZ 3123

Documents

IPD Product Catalogue V17
