IPD W66US432 Unswitched Socket 4 Round-Pin 3-Ph 32A 500VAC/DC IP66 Polycarbonate

Product Code: W66US432

  • 32A socket with IP66 protection
  • Supports 500 VAC/VDC voltage
  • Made from durable polycarbonate
  • Includes M32 and M25 gland entries
  • Complies with AS3123 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Unwitched Socket
Brand
IPD
Series
W66

Electrical

No. of Phases
3 phase
Rated Current (In)
32A
Rated Voltage (Ur)
500V
No. of Switching Poles
3
With Neutral Conductor
Yes

Mechanical

Colour
Light Grey
Gland Entries
1 x M32, 2 x M25
Material
Polycarbonate
No. of Pins
4 Pin
Pin Type
Round
Max. Cable Size
16 mm²

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZ 3123

Documents

IPD Product Catalogue V17
