IPD W66US315 Unswitched Socket 3 Flat-Pin 1-Ph 15A 250VAC/DC IP66 Polycarbonate

Product Code: W66US315

  • 15A socket with flat pin type
  • IP66 rated for robust protection
  • Suits 250 VAC/VDC applications
  • Durable polycarbonate material
  • Includes back box and gland entries
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Unwitched Socket
Brand
IPD
Series
W66

Electrical

No. of Phases
1 phase
Rated Current (In)
15A
Rated Voltage (Ur)
250V
No. of Switching Poles
2
With Neutral Conductor
Yes

Mechanical

Colour
Light Grey
Gland Entries
1 x M32, 2 x M25
Material
Polycarbonate
No. of Pins
3 Pin
Pin Type
Flat
Max. Cable Size
6 mm²

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZ 3123

Documents

IPD Product Catalogue V17
