IPD W66IS332LB Motor Rated Isolating Switch 3-P 32A 500VAC/DC IP66 Polycarbonate

Product Code: W66IS332LB

  • 32 A, 3-pole isolator for reliable control
  • IP66 rating ensures high protection
  • Supports 500 VAC/VDC applications
  • Durable polycarbonate construction
  • Multiple gland entries for easy wiring
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Isolating Switch
Brand
IPD
Series
W66

Electrical

No. of Phases
3 phase
Rated Current (In)
32A
Rated Voltage (Ur)
500V

Mechanical

Colour
Light Grey
Gland Entries
2 x M25, 1 x M32
Material
Polycarbonate
No. of Pins
Base not included
Max. Cable Size
16 mm²

Dimensions & Physical Data

Depth
109mm
Height
101mm
Width
101mm

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
EN/IEC 60309-2

Documents

IPD Product Catalogue V17
