IPD W66IS220LB Motor Rated Isolating Switch 2-P 20A 250VAC/DC IP66 Polycarbonate

Product Code: W66IS220LB

  • 20A isolator for reliable power control
  • Compact size: 101mm width & height
  • IP66 rated for robust protection
  • Dual voltage: 250 VAC/VDC compatible
  • Durable polycarbonate construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Isolating Switch
Brand
IPD
Series
W66

Electrical

No. of Phases
1 phase
Rated Current (In)
20A
Rated Voltage (Ur)
250V

Mechanical

Colour
Light Grey
Gland Entries
2 x M25, 1 x M32
Material
Polycarbonate
No. of Pins
Base not included
Max. Cable Size
16 mm²

Dimensions & Physical Data

Depth
109mm
Height
101mm
Width
101mm

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
EN/IEC 60309-2

Documents

IPD Product Catalogue V17
