IPD TSC35 Bolt-In High Speed Traction Fuse 35A 1200VAC 26mm Dia x 139mm L 63kA 124mm gL gG

Product Code: TSC35

  • Bolt-In type with 35 A rated current
  • Complies with BS 2692-1 standards
  • Supports up to 1200 VAC voltage
  • High breaking capacity of 63 kA
  • Designed for holder mounting
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
IPD
Series
TSC
Application
High speed traction fuse for AC / DC traction applications.

Electrical

Utilization Category
High speed / traction
Breaking Capacity
63kA
Rated Current (In)
35A
Rated Voltage (Ur)
1200V AC / 660V DC
Speed Class
High Speed

Mechanical

Body Style
Offset bolted tags
Fixing Centres
124mm
Indicators
without indicator
Mounting
Bolt-in
Size Code
26 x 139
Connection/Termination
Offset bolted tags
Fuse Holder
RSL63 fuse-holder

Dimensions & Physical Data

Length
139mm
Weight
0.1347kg (Approx.)
Width
Ø 27mm

Safety, Standards & Compliance

Standards and Approvals
BS2692-1

Documents

IPD Product Catalogue V17
